Most filament printers top out around 300 °C and never need to go higher. The Apium P220 lives in a different world: a 540 °C extruder, a 160 °C build plate, and a material list headed by PEEK — a semi-crystalline thermoplastic that costs as much per kilogram as some entire desktop printers. Built by Apium Additive Technologies of Karlsruhe, Germany, the P220 is one of the machines that defined the compact industrial high-performance-polymer category, and it remains a fixture on PEEK printer shortlists. If you have seen the name and wondered what the machine actually is, here is the full picture.

The Machine

The P220 is a fused filament fabrication (FFF) printer with a 205 × 155 × 150 mm build volume — deliberately small by industrial standards, at roughly 4.8 liters. According to Aniwaa's product listing, the extruder reaches 540 °C, the build plate 160 °C, and the zone around the part a maximum of 180 °C, with a minimum layer height of 0.05 mm. The whole machine measures 850 × 685 × 675 mm and weighs 65 kg — benchtop scale, not a walk-in cell. Aniwaa lists pricing from about $29,000 (€25,000), which positions the P220 at the accessible end of industrial PEEK printing.

The material list is the point. Apium's own literature centers on PEEK and ULTEM (PEI), and Aniwaa's spec sheet extends the range to carbon-fiber-reinforced PEEK, PEKK and other PAEK-family polymers, plus commodity materials like ABS and polypropylene. When 3D Printing Industry reviewed the machine, it noted the printer is designed for high-performance polymers including PEEK, carbon-fiber-reinforced PEEK, POM-C, PVDF, and PEI 9085.

Why PEEK Is Hard to Print

PEEK melts at 343 °C, so the extruder has to run well past the limits of ordinary hotends. But the melting point is the easy part. As Aniwaa's PEEK printer guide explains, the real fight is thermal management after the plastic leaves the nozzle. PEEK's glass transition temperature sits around 143 °C, and if the printed part cools below that unevenly, it warps — the signature failure mode of high-performance polymer printing. The conventional answer is a heated chamber at or above the glass transition temperature, plus gradual, controlled cooling so the polymer crystallizes properly; parts sometimes need hours on the bed before removal. Many workflows add a post-print annealing cycle to improve part quality and dimensional stability.

Crystallinity is the reason all this matters. PEEK is semi-crystalline, and its headline mechanical and chemical properties depend on how much of the polymer actually crystallizes as it cools. Cool it too fast and you get a partly amorphous, weaker part. That thermal sensitivity — plus filament that runs $400 to $700 per kilogram, per Aniwaa — is why PEEK machines are engineered and priced the way they are. (For the material side of this story, see our earlier explainer on PEEK and ULTEM filaments.)

Adaptive Heating: Apium's Answer

Where most competitors chase ever-hotter chambers, Apium's approach is different. The P220's patent-pending Adaptive Heating System manages thermal influences on the part throughout the entire print, heating defined areas at defined times rather than soaking the whole build space. Apium claims the system achieves 29–32% crystallinity in PEEK, produces mechanical properties that compete with injection-molded parts, prevents geometric deformation, and eliminates the need for post-processing annealing — the crystallization work happens on the machine.

3D Printing Industry's hands-on review called the system one of the machine's most important features. With the adaptive heating active, layer adhesion improved noticeably compared to runs with it disabled — to the point that support structures became harder to remove because they bonded so strongly to the part.

How It Prints in Practice

That 2018 review remains one of the most detailed independent looks at the P220. Simple geometries — squares, cylinders — printed excellently in PEEK, and functional elements like 5 cm gears and hinges came out perfectly. Torture tests exposed the limits: slight corner warping on complex PEEK parts, and features under 2 mm exceeded the machine's accuracy. The reviewers also highlighted practical touches, including interchangeable nozzles that swap in about two minutes and a Direct Print feature that sliced models in under ten seconds. Notably, the P220 is produced at a Heidelberger Druckmaschinen facility — Apium leaning on German press-manufacturing infrastructure for build quality.

Who Buys a Machine Like This

Apium co-founder Brando Okolo, who started the company in August 2014 with Tony Tran-Mai (originally under the name Indmatec), has been explicit about the target market: medical, aerospace, and R&D, serving mass customization rather than mass production. That maps onto where PEEK and ULTEM actually earn their price premium. Aerospace uses them as lightweight metal replacements — ULTEM has flown for decades and is heavily certified. Medical device makers value PEEK's biocompatibility and the fact that it does not interfere with MRI or CT imaging. Oil and gas operations use its chemical resistance for parts like valves, and the electronics industry exploits its electrical properties for printed circuit boards and insulation. The P220 itself was announced at Formnext in November 2016 as the larger successor to Apium's P155, with customer demand for more build volume driving the redesign.

The P220 Against the Field

Aniwaa's buyer's guide puts the competitive landscape in one table. The Intamsys FUNMAT PRO 410 (~$23,000) undercuts the P220 on price and offers a much larger 305 × 305 × 406 mm build volume, but its chamber reaches only 90 °C. The 3DGence INDUSTRY F421 (~$50,000) brings a 195 °C chamber; miniFactory's Ultra (~$65,000) hits 250 °C and integrates an annealing system; the 3ntr Spectral 30 (~$110,000) pairs a 250 °C chamber with four 500 °C extruders. At the top sits the Stratasys Fortus 450mc, quoted on request, with a 406 × 355 × 406 mm build volume and a certified ULTEM ecosystem. The P220's pitch within that field is repeatability in a small footprint: Aniwaa singles out the adaptive heating for delivering tight tolerances, and Apium's crystallinity numbers are the machine's calling card. If your parts fit in a 205 × 155 × 150 mm envelope and your priority is consistent, fully crystallized PEEK without a separate annealing step, the P220 makes the shortlist. If you need volume, the money points elsewhere.
